Description of the product
Paving grade bitumen 20/30 is the hardest paving grade bitumen offered by ORLEN Group. Its high softening point and high sensitivity to low-temperature cracks renders it recommendable solely for the binder and base courses of high-stiffness modulus asphalt concrete (AC EME) in regions with suitable climate. Courses with bitumen 20/30 should not be left over the winter period without being covered with the next course. Additionally, for main roads, in WT-2 part I of 2014 [6] are given special requirements and climate zones where specific types of binders (paving grade 20/30 or polymer modified) are used in AC EME.
Properties
| Property | Unit | Test method | Requrement |
|---|---|---|---|
| Penetration at 25°C |
0.1 mm | EN 1426 | 20 - 30 |
| Softening point | °C | EN 1427 | 55 - 63 |
| Resistance to hardening at 163°C | EN 12607-1 (RTFOT method) | - | |
| Retained penetration | % | EN 12607-1 (RTFOT method) | ≥ 55 |
| Increase in Softening point | °C | EN 12607-1 (RTFOT method) | ≤ 8 |
| Change of mass* (absolute value) | % | EN 12607-1 (RTFOT method) | ≤ 0.5 |
| Flash point | °C | EN ISO 2592 | ≥ 240 |
| Solubility | % (m/m) | EN 12592 | ≥ 99.0 |
